Product Overview

DADCO SUPER PROOF is a premium cold applied damp proofing coating specially formulated with superior bitumen adhesive properties and selected petroleum solvents. This advanced coating provides exceptional moisture protection for demanding applications in extreme climate conditions, suitable for temperatures exceeding 50°C with enhanced performance characteristics.

Key Characteristics

• Superior Adhesion: Enhanced bitumen formulation for maximum bonding strength
• Cold Application: No heating required – ready to use at ambient temperature
• Extreme Temperature Resistance: Suitable for direct sunlight and temperatures above 50°C
• Fast Drying: 6-hour touch dry, 12-hour through dry for efficient scheduling
• Enhanced Coverage: Optimized viscosity for superior surface coverage
• Extended Shelf Life: 12-month storage life in unopened sealed containers

Primary Functions

DADCO SUPER PROOF provides excellent damp proofing protection for:

• Foundation Systems: Above and underground foundation waterproofing
• Bridge Infrastructure: Moisture protection for bridge foundations and structures
• Culvert Applications: Waterproofing of drainage systems and water channels
• Retaining Walls: Comprehensive protection for retaining wall structures
• Vertical Surfaces: High-performance coating for walls exposed to extreme weather conditions
• Industrial Applications: Heavy-duty moisture protection for commercial facilities

Application Instructions

Surface Preparation:

• Ensure surface is clean, dry, and free from dust, dirt, grease, and oil
• Remove any loose materials, efflorescence, or surface contamination
• Allow adequate curing time for new concrete before application
• Repair structural defects and ensure surface integrity

Application Process:

• No Heating Required: Apply directly from container at ambient temperature
• Mixing: Stir thoroughly to homogenize solution before use
• Application Methods: Apply using brush or roller for uniform coverage
• Surface Coverage: Suitable for concrete walls, roofs, and masonry surfaces
• Coverage Rate: 400-500 gms/m² depending on surface conditions and temperature

Technical Specifications

Physical Properties:

• Kinematic Viscosity @60°C: 100-120 CST (ASTM D-2170)
• Density @25°C: 0.80-0.95 (ASTM D-70)

Distillation Characteristics:

• Distillate Volume % Primer:
  • Up to 225°C: Not less than 30% (ASTM D-402)
  • Up to 360°C: Not less than 60% (ASTM D-402)

Performance Properties:

• Residue Penetration @25°C: 20-40 dmm, 100 gms, 5 sec (ASTM D-5)
• Solubility in Trichloroethylene: 99% minimum (ASTM D-2042)
• Drying Time (To Touch): 6 hours
• Drying Time (To Through): 12 hours
• Coverage Rate: 400-500 gms/m² (concrete walls and roofs, dependent on dry film thickness and temperature)

Packaging & Storage

Available Packages:

• Standard Container: 100 Liters per drum
• Large Container: 200 Liters per drum
• Bulk Supply: Custom packaging available for large projects

Storage Requirements:

• Store material in shaded area away from direct heat sources
• Maintain containers in cool, dry, well-ventilated locations
• Ensure proper sealing to prevent solvent evaporation
• Protect from extreme temperature fluctuations and moisture contamination

Shelf Life:

• Unopened Sealed Container: 12 months from manufacture date
• Storage Conditions: Ambient temperature in shaded environment
• Quality Maintenance: Retains superior performance characteristics throughout shelf life

Health & Safety

DADCO SUPER PROOF is a bituminous product requiring appropriate safety precautions:

• Personal Protection: Wear gloves, mask, and safety goggles during handling and mixing
• Skin/Eye Contact: Avoid contact with skin or eyes
• Ventilation: Ensure adequate ventilation during application, especially in enclosed areas
• Fire Safety: Keep away from heat sources, sparks, and open flames
• Emergency Response: Follow comprehensive material safety data sheet procedures

Quality Standards

• ASTM D-2170: Kinematic viscosity testing compliance
• ASTM D-70: Density measurement standards
• ASTM D-402: Distillation testing procedures
• ASTM D-5: Penetration testing standards
• ASTM D-2042: Solubility testing compliance
• ISO Certification: International quality management systems
• SASO Quality Mark: Saudi Arabian Standards Organization approval

Technical Support

Comprehensive technical support available covering application procedures, surface preparation guidelines, coverage calculations, and performance optimization. Contact DADCO technical specialists for project-specific consultation, detailed application instructions, and professional troubleshooting assistance.

Performance Advantages

• Enhanced Protection: Superior moisture barrier performance in extreme conditions
• Temperature Stability: Maintains integrity under high-temperature exposure
• Improved Adhesion: Advanced bitumen formulation for lasting bond strength
• Efficient Application: Optimized viscosity for uniform coverage and reduced waste
• Cost Effective: High-performance coating reduces long-term maintenance requirements

Environmental Considerations

• Dispose of waste materials according to local environmental regulations
• Use appropriate containment measures during application
• Follow environmental protection guidelines and best practices
• Minimize solvent emissions through proper application techniques
